AISI 446 Pipe, SUS 446 Pipes, 446 Stainless Steel Pipe, Uns S44600 Seamless Pipe, ASTM A268 TP446 Pipes
Bhawal Steel Agency manufactures various products related to steel. Stainless steel variation 446 pipes and tubes are also simulated in different ranges of size and shapes, all of which are designed to follow domestic and international raw materials quality requirements.
This pipe and tubes, also known as UNS S44600, are non-hardenable, high chromium stainless steel, which has high corrosion resistance. SS 446 Alloy is particularly resistant to corrosion abrasion, scaling, atmospheric sulfurization and oxidation. Bhawal Steel Agency offers 446 stainless steel, also known as WNR 1.4762 / 3, available at customer market leading prices.
The SS 446 pipes are suitable to use between 1500 - 2100 °F, but the elevated temperature tolerance is very low. SS 446 are mainly used for oil burners, turbine parts, heat exchangers, glass moulds, and stationary soot blowers in steam boilers.
The operation scope of SS 446 pipes/tubes are gas pipes & tubes, oil pipe & tubes, boiler pipe & tube, heat exchanger and fluid pipe & tube.
Wall thickness is available from 0.4-30 mm, length is up to 24", and their types are known as cold drawn, seamless, welded, structural, hot finished, annealed and pickled, extruded, etc., are the standard specifications of our SS 446 pipe grade. Respected Clients may order stainless steel 446 pipes in custom lengths and shapes. The SS 446 welded tubes can also be machined and designed according to customers' requests for piping specifications.
For more information, you also contact us; we are here to assist you 24x7.
446 Stainless Steel Pipe Specification
| Alloy 446 Specification | Stainless Steel 446, Stainless Steel UNS S44600 |
|---|---|
| SS 446 Pipe | 446 Stainless Steel Pipe |
| WERKSTOFF NR. 1.4762 / 1.4763 SS 446 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Stainless Steel 446 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| SS 446 EFW Pipe size | 5.0 mm – 1219.2 mm |
| 446 Stainless Steel Pipe Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| A269 stainless steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| SS 446 Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| 446 Stainless Steel Tube wall thickness | 0.020" –0.220", (special wall thicknesses available) |
| WERKSTOFF NR. 1.4762 / 1.4763 Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| SS UNS S44600 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| ASTM A312 TP 446 Stainless Steel Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Stainless Steel 446 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| WERKSTOFF NR. 1.4762 / 1.4763 End | Plain End, Beveled End, Treaded Pipe |
| WERKSTOFF NR. 1.4762 / 1.4763 SS 446 Marking | All 446 Stainless Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| UNS S44600 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Stainless Steel UNS S44600 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| 446 Steel Specialize in |
|
| ASTM A 312 SS 446 Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Manufacturers of 446 Stainless Steel Pipe |
|
| We can also cut, thread, and groove 446 Stainless Steel Pipe to meet your specifications. Pipe Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
446 Stainless Steel Pipe Sizes
| 1/8" IPS(.405" O.D.) | 3 1/2" IPS( 4.000" O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4" IPS(.540" O.D.) | 4" IPS(4.500" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8" IPS(.675" O.D.) | 5" IPS( 5.563" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2" IPS(.840" O.D.) | 6" IPS(6.625" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4" IPS(1.050" O.D.) | 8 ” IPS(8.625" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS:(1.315′ O.D.) | 10" IPS(10.750" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4" IPS(1.660" O.D.) | 12" IPS(12.750" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2" IPS(1.900" O.D.) | 14" IPS(14.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2" IPS(2.375" O.D.) | 16" IPS(16.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2" IPS(2.875" O.D.) | 18" IPS (18.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3" IPS( 3.500" O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
446 Stainless Steel Pipe composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 446 | min. | – | – | – | – | – | 23.0 | – | – | 0.10 |
| max. | 0.2 | 1.5 | 0.75 | 0.040 | 0.030 | 30.0 | – | 0.50 | 0.25 | |
446 Stainless Steel Pipe mechanical properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 446 | 485 | 275 | 20 | 92 | 201 |
Equivalent Grades for 446 Stainless Steel Pipe
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 446 | S44600 | – | – | 1.4762 / 1.4763 | – | – | – |
